AUBO Largest collaborative robot 6 axis cobot i10 paylaod 10kg automation low cost collaborative robot
Product Details:
| Place of Origin: | Shanghai, China |
| Brand Name: | Aubo |
Payment & Shipping Terms:
| Price: | Negotiable |
|---|---|
| Packaging Details: | One AUBO Largest collaborative robot 6 axis cobot i10 paylaod 10kg automation low cost collaborative robot packing with fumigation wooden frame, WG: 57 KG<br>Controller and other parts packing with brown box, WG: 30 KG<br>Total WG: 87KG(>VG) |
| Supply Ability: | 5 Piece/Pieces per Month |
|
Detail Information |
|||
| Product Name: | AUBO Cobot I10 | Number Of Axis: | 6 Axis |
|---|---|---|---|
| Max Payload: | 10 Kg | Maximum Reach: | 1513 Mm |
| Pose Repeatability(ISO 9283): | ±0.1mm | Material: | Aluminum Alloy |
| Protection Rating: | IP54 | Mounting Position: | Floor/ Ceiling/Wall |
| Life Time: | >30000h | Warranty: | 1 Year, 1 Year |
| Condition: | New | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | New Product 2020 |
| Warranty Of Core Components: | 1 Year | Core Components: | PLC, Engine, Bearing, Gearbox, Motor |
| After-sales Service Provided: | Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Video Technical Support, Online Support | After Warranty Service: | Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service |
| Local Service Location: | United States, France, Germany, Viet Nam, Indonesia, Australia, Argentina, Algeria | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
| Showroom Location: | United Kingdom, United States, France, Viet Nam, Brazil, Indonesia, Russia, Argentina | Port: | Shanghai |
Product Description
AUBO Largest collaborative robot 6 axis cobot i10 paylaod 10kg automation low cost collaborative robot
Main Specifications
Maximum reach:1513 mm
Maximum payload:10kg
Pose repeatability (ISO 9283):± 0.1 mm
Number of axes:6
Mounting position:Floor/ Ceiling/Wall
Lifetime:30000h
Standard:CE, TUV,KSc
Power consumption:500W
Power supply:DC 48V
I/O port:16 in/16 out
Screen:12 inch Resistive LCD touch screen
| Product Name | AUBO Largest collaborative robot 6 axis cobot i10 paylaod 10kg automation low cost collaborative robot |
| Application | AUBO Largest collaborative robot 6 axis cobot i10 paylaod 10kg automation low cost collaborative robot ,mainly application in automobile making and welding |
| Model | Aubo i10 |
| Robot Arm | |
| Maximum reach | 1513 mm |
| Maximum payload | 10 kg |
| Pose repeatability (ISO 9283) | ± 0.1 mm |
| Number of axes | 6 |
| Mounting position | Floor/ Ceiling/Wall |
| Lifetime | 30000h |
| Weight | 15.5 kg |
| Protection rating | IP54 |
| Standard | CE, TUV,KSc |
| Power consumption | 500W |
| Material | Aluminum alloy |
| Ambient temperature | 0-45°C |
| Environment humidity | 20-85%(No condensation) |
| Power supply | DC 48V |
| Protocol | CAN bus |
| A1 | ±175° |
| A2 | ±175° |
| A3 | ±175° |
| A4 | ±175° |
| A5 | ±175° |
| A6 | ±175° |
| Controller | |
| Size | 380mm*350mm*258mm |
| Weight | 15Kg |
| Cable length | 5m |
| Colour | Black |
| Protocol | Ethernet,Modbus-RTU/TCP |
| Power | 100-240V/AC,50-60HZ |
| Protection rating | IP54 |
| I/O port | 16 in/16 out |
| Teach pendant | |
| Size | 355mm*235mm*54mm |
| Weight | 1.57Kg |
| Screen | 12 inch Resistive LCD touch screen |
| Cable length | 4m |
| Protection rating | IP54 |
| Colour | Orange+black |
