Product Features:
Innovatively adopting the product design principles of JAKA S³ (Smart, Simple, Small), and integrating with advanced robot
technologies such as wireless teaching, graphical programming and visual protection, it revolutionizes the way of Human-Cobot
interaction, improves the safety of human-machine cooperation and greatly reduces the threshold of robots using. Meanwhile, JAKA
All-in-one Cobots deeply integrates plug-and-play vision to ensure the natural interaction and autonomous adaptation among cobot,
human and operating environment, which significantly broadens the application boundary of robot.
 |
China robot JAKA Ai 3 collaborative robot controller with 6 axis used as mini industrial robot
Product Details:
| Place of Origin: | Shanghai, China |
| Brand Name: | jaka |
Payment & Shipping Terms:
| Price: | Negotiable |
|---|---|
| Packaging Details: | One JAKA Zu7 2.0 version 6 axis collaborative robot low cost joint robot integration industrial cobot high payload and design packing with fumigation wooden frame, WG: 22KG<br>Controller and other parts packing with brown box, WG: 30 KG<br>Total WG:52 KG |
| Supply Ability: | 5 Set/Sets per Month |
|
Detail Information |
|||
| Condition: | New | Warranty: | 1 Year, 1 Year |
|---|---|---|---|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops | Weight (KG): | 60 |
| Showroom Location: | Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, Mexico, Russia, Argentina | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | New Product 2020 |
| Warranty Of Core Components: | 1 Year | Core Components: | Bearing, Gearbox |
| Product Name: | JAKA Zu7 2.0 Version | Number Of Axis: | 6 Axis |
| Max Payload: | 7 Kg | Maximum Reach: | 819mm |
| Pose Repeatability(ISO 9283): | ±0.03mm | Material: | Aluminum,PC |
| Protection Rating: | IP54 | Mounting Position: | Installation At Any Angle |
| Life Time: | 30000h | Port: | Shanghai |
Product Description
JAKA AI 3 cobot
Model | jaka Ai 3 cobot |
Maximum reach | 626 mm |
Maximum payload | 3 kg |
Weight | 12 kg |
Power | 150 W |
Repeatability | ±0.02mm |
Axis | 6 |
Teach pendant | MT(PAD/Mobile)APP |
Collaborative operation | In compliance with GB 11291.1-2011 |
Product Features
1.Multiple Models This series of robots can be used in small parts assembly, dispensing, machine tending, material handling, electronics and many other applications in general industrial fields. 2.Reliable Performance It can adapt to harsh working environment, and can also be equipped with integrated joints which are easy to disassemble and transport. 3.Easy to Maintain Considering that improving maintainability is a key factor to reduce costs, the robot's after-sales and maintenance time is reduced by 15%. 4.Technical Support We will provide you with long-term technical services. If you have any technical problems or other needs during using our robot, you are welcome to contact us.
