4.4 kw Popular High Torque 2000rpm 220V Electric 180mm 5 Poles Servo Motor CE RoHS Standard CNC Lathe Servo Motor
Specification
|
item
|
value
|
|
Warranty
|
3months-1year
|
|
Place of Origin
|
China
|
|
|
Zhejiang
|
|
Brand Name
|
Xinyuhai
|
|
Model Number
|
180SY-M28015S1
|
|
Type
|
SERVO MOTOR
|
|
Product Name
|
HIGH EFFICIENCY SERVO MOTOR
|
|
Color
|
Black
|
|
Rated Power
|
4.4KW
|
|
Voltage
|
220V
|
|
Rated Speed
|
1500RPM
|
|
Max. speed
|
2000RPM
|
|
Poles
|
5
|
|
Torque
|
28-44.8N.m
|
|
Function
|
Ac Motor Specification
|
|
Utilization Environment
|
0-55℃
|
|
Poles
|
5
|
|
Absolute Encoder
|
17/33bit, 25/41bit, 23/39bit
|
|
Humidity
|
<90%
|
|
Insulation Class
|
B
|
|
Protection Class
|
IP65
|
|
Insulation Dielectric
|
AC1500V, 1min
|
|
Insulation Resistance
|
DC500V, >10M
|
|
Vibration
|
<2.5G
|
|
Altitude
|
<1000m
|
|
Working Type
|
Continuous
|
|
Installment
|
Flange
|
Product Description
180 S1 Series AC permanent magnetic servo mortor
As a superior servo motor of Xinyuhai,180 S1 series servo motor guarantees high rotation speed under low rated power when functioning,furthermore it ensured good stability because of unique design of whole motor. High quality and Stability are accomplished via accessories selection, assemblage and inspection.
FangYu 5 pole pairs series all adopt potting technique which assists on inertia, rigidity improvement, thus the whole
machine gets a faster response. With relatively low limited temperature increase, torque force of the motor is greatly improved and overload capability is strengthened. Within very short time, the speed of 180S1 can up to maximum 2000 r/m according to different models. Strictly slected material accessories permanent magnetic design and serious assemblage also ensured longevity and durable usage of the motor.
We offer customization options, some critical configuration parameters are changeable. If you need any special requirements, pls contact us FREELY. We strongly recommend that clients use our coordinated driver to achieve best functions of the motor.
