Robot Vacuum Cleaner PCB & PCBA Assembly Sensors Charger
If desired, we will source, organise and manage all aspects of the PCB design, so that your product meets all required standards and is fully optimised for easy and cost effective manufacturing.
A well designed circuit board means:
· A reduction in production problems
· Improved quality control
· Reduced costs
· Reduced manufacturing times
|
Our advantage
|
||||
|
Material Technology
|
Our Production
|
General Production
|
||
|
Regular/Special
|
1.Our (TG170)FR4:
high quality materials, excellent heat resistance, won't distort break in high temperature, no foaming, no burning, good performance in electrical charge, impact resistance, humidity-resistance 2.Our FR4 good performance in electrical charge, impact resistance, humidity-resistance 3.Our CEM no-burr 4.Our Rogers Good performance in high frequency 5.Our Aluminum Excellent heat dispersion |
1.General FR4
High heat work 2.General CEM Expand and deform in damp conditions |
||
|
Factory
|
We have automatic production line. The automatic production line improves the precision and efficiency of PCB producing,it makes
surface brighter, cleaner and more smooth, and it helps reduce the cost. |
Artificial production line
|
||
|
Blind/buried via board, High Density Interconnect(1+1,N+1)
|
Application of HDI technology reducing the thickness and the volume of PCB boards, increasing the density of 3-D wiring design.
|
Difficult manufacturer, high cost
|
||
|
Impedance
|
Good performance in reliability and stability of signal sending and receiving
|
High cost
|
||
|
Surface Technics
|
1.IMG:smooth surface, good adhesion, no oxidation under long using
2.gold plating(thick gold:1-50U"):good wear-resistance 3.HASL:better price, not easy oxidation, easy to welding, smooth surface 4.HAL: better price, not easy oxidation, easy to welding |
1.IMG:high price
2.Gold plating(thick gold):high price 3.HAL:surface is not flat, not suitable for BAG packaging |
||
|
Copper Via/Surface(20-25UM,0.5-60Z)
|
Laser holing: Min 0.1MM, Mechanical holing: Min 0.2MM
|
Hard to reach 0.1MM
|
||
|
Multilayer board(4-20 L),BGA(CPU)
|
BGA:high density, high performance, multifunctional, increase thermal reliability, good performance in electroheat property, MIN
width/space: 3/3MIL Multilayer board:strong microporous, high reliability |
Difficult manufacturer,high cost
|
||
|
Test
|
To assure quality, avoid wasting after installing and scraping, save cost, save the time of rework
|
Careless
|
||
It can be a challenge to find the optimal supplier for PCBs – meeting each and all customers’ expectations and requirements on price, quality, lead times, value-added services, and delivery. Wonderful PCBs is confidant that we meet each and every expectations for your each PCB.
