CE E05 5KG 800mm Welding Robot Arm Aluminum Alloy
Product Details:
| Place of Origin: | Shanghai, China |
| Brand Name: | Han's |
| Certification: | CE |
Payment & Shipping Terms:
| Price: | Negotiable |
|---|---|
| Packaging Details: | Hans Standard Package |
| Supply Ability: | 50 Set/Sets per Month |
|
Detail Information |
|||
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising Company | Showroom Location: | United Kingdom, Germany, Viet Nam, Russia |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Not Available |
| Marketing Type: | Hot Product 2020 | Warranty Of Core Components: | 1 Year |
| Core Components: | Motor | Condition: | New |
| Horizonal Travel(mm): | 590mm | Weight: | 28 Kg, 23 Kg |
| Dimension(L*W*H): | 790mmX560mmx390mm | Warranty: | 1 Year |
| Product Name: | Cobot | Maximum Reach: | 800mm |
| Maximum Payload: | 5 Kg | Usage: | Multifunctional Usage |
| Number Of Axis: | 6 | Mounting Position: | Any Angel |
| Protection Rating: | IP54/IP65 | Power: | DC48V |
| Ambient Temperature: | 0-45℃ | After Warranty Service: | Video Technical Support, Online Support, Spare Parts |
| Local Service Location: | None | After-sales Service Provided: | Online Support |
| Port: | Shanghai | ||
| High Light: | 590mm 800mm welding robot arm,590mm 5KG welding robot arm,590mm Aluminum Alloy axis robot |
||
Product Description
|
Model
|
Han's Elfin E05
|
|
Maximum reach
|
800mm
|
|
Maximum payload
|
5kg
|
|
Weight
|
23 kg
|
|
Power
|
100W
|
|
Joint Range
|
±360º
|
|
Max Speed
|
2m/s
|
|
Repeatability
|
±0.03mm
|
|
End I/O Port
|
Digital Input:3, Digital Output:3, Analog input:2
|
|
Control Box I/O Port
|
Digital Input:16, Digital Output:16, Analog input:2, Analog output:2
|
|
I/O Source
|
24V 2A
|
|
Communication
|
TCP/IP, Modbus, EtherCAT
|
|
Programming
|
graphical programming, remote process call
|
|
IP Classification
|
IP54/IP66
|
|
Collaborative Operation
|
10 advanced configurations for Safety
|
|
Robot Body Material
|
Aluminum Alloy
|
|
Power Input
|
200-240V AV 50-60Hz
|
|
Cable
|
Cable between Robot and controller:5m, Cable between Teach pedant and controller:5mm
|
Product Features
1.Multiple Models This series of robots can be used in small parts assembly, dispensing, machine tending, material handling, electronics and many other applications in general industrial fields. 2.Reliable Performance It can adapt to harsh working environment, and can also be equipped with integrated joints which are easy to disassemble and transport. 3.Easy to Maintain Considering that improving maintainability is a key factor to reduce costs, the robot's after-sales and maintenance time is reduced by 15%. 4.Technical Support We will provide you with long-term technical services-Online Support, Video Support. If you have any technical problems or other needs during using our robot, you are welcome to contact us.
FAQ
Q.What is Your Payment Term?
A:Normally T/T 30% in advance, balance to be paidbefore delivery, We also support the trade assurance,OlA.
Q:What is Trade Assurance? A:Trade Assurance is a free service by Alibaba.comthat's designed to help create trust between buyers andsuppliers.Trade Assurance helps buyers in the event ofshipping and quality-related dispute.
Q:Does Trade Assurance Charge Fees? A:No.Trade Assurance is free for both buyers andsuppliers.
Q:What Kind of Trade Terms Can You Do?
A:EX-WORKS,FOB,CFR,CIF,etc.
