6 axis handling robot China Hans E10 payload 10Kg reach 1000mm cheap CNC collaborative robot arm
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | Hans |
| Certification: | CE/ROHS |
Payment & Shipping Terms:
| Price: | Negotiable |
|---|---|
| Packaging Details: | One 6 axis handling robot China Hans E10 payload 10Kg reach 1000mm cheap CNC collaborative robot arm packing with Brown box: WG: 65 KG<br>Controller and other parts packing with brown box, WG: 30 KG<br>Total WG: 95 KG(>VG) |
| Supply Ability: | 10 Set/Sets per Month |
|
Detail Information |
|||
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, Advert | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 1 Year |
| Core Components: | PLC, Gearbox | Condition: | New |
| Weight: | 65Kg | Dimension(L*W*H): | 80*80*80cm |
| Power: | 5KW | Warranty: | 1 Year, 1 Year |
| Product Name: | 6 Axis Handling Robot Hans E10 Collaborative Robot Arm | Number Of Axis: | 6 Axis |
| Max Payload: | 10 Kg | Maximum Reach: | 1000 Mm |
| Pose Repeatability(ISO 9283): | ±0.05mm | Material: | Aluminum Alloy |
| Protection Rating: | IP54 | Mounting Position: | Floor/ Ceiling/Wall |
| Life Time: | 30000h | After Warranty Service: | Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service |
| Local Service Location: | None | After-sales Service Provided: | Online Support |
| Port: | Shanghai | ||
Product Description
6 axis handling robot China Hans E10 payload 10Kg reach 1000mm cheap CNC collaborative robot arm
Main Specifications:
Maximum reach:1000 mm
Maximum payload:10 kg
Pose repeatability (ISO 9283):± 0.05 mm
Number of axes:6
Mounting position:Floor/ Ceiling/Wall
Lifetime:30000h
Standard:CE, TUV,KSc
Power consumption:200W
Power supply:DC 48V
I/O port:16 in/16 out
Screen:12 inch Resistive LCD touch screen
| Product Name | 6 axis handling robot China Hans E10 payload 10Kg reach 1000mm cheap CNC collaborative robot arm |
| Application | 6 axis handling robot China;collaborative robot arm;handling robot |
| Model | Elfin 10 |
| Robot Arm | |
| Maximum reach | 1000 mm |
| Maximum payload | 10 kg |
| Pose repeatability (ISO 9283) | ± 0.05 mm |
| Number of axes | 6 |
| Mounting position | Floor/ Ceiling/Wall |
| Lifetime | 30000h |
| Weight | 29 kg |
| Protection rating | IP54 |
| Standard | CE, TUV,KSc |
| Power consumption | 200W |
| Material | Aluminum alloy |
| Ambient temperature | 0-45°C |
| Environment humidity | 20-85%(No condensation) |
| Power supply | DC 48V |
| Protocol | CAN bus |
| A1 | ±135° |
| A2 | ±135° |
| A3 | ±135° |
| A4 | ±135° |
| A5 | ±135° |
| A6 | ±135° |
| Controller | |
| Size | 536mm*445mm*491mm |
| Weight | 20Kg |
| Cable length | 5m |
| Colour | Black |
| Protocol | Ethernet,Modbus-RTU/TCP |
| Power | 100-240V/AC,50-60HZ |
| Protection rating | IP54 |
| I/O port | 16 in/16 out |
| Teach pendant | |
| Size | 355mm*235mm*54mm |
| Weight | 1.8Kg |
| Screen | 12 inch Resistive LCD touch screen |
| Cable length | 4m |
| Protection rating | IP54 |
| Colour | Orange+black |
1.Swift delivery
For common parts, we can deliver the goods within 3 days
2.Original products
All the products we sell are from origin manufacturer. We will submit all the manufacturer documentation while we finish delivery.
3.Quality Assurance
4.Technical Support
Including inspection,repair and maintenance, we can give all kinds of technical support.
5.Quickly responce
Our staffs will keep 24h online and answer your question very quickly.
