ZH100U 6 Axis Industrial Robot Assembly With E04 Controller
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | KAWASAKI |
| Certification: | CE |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wodden cartons or meet customers' requirements |
| Delivery Time: | 6-8 weeks |
| Payment Terms: | L/C, D/A, D/P, T/T |
| Supply Ability: | 999 sets/month |
|
Detail Information |
|||
| Number Of Axes: | 6axis | Pose Repeatability: | ±0.05mm |
|---|---|---|---|
| Type: | Kawasaki Palletizing Arm | After Warranty Service: | Video Technical Support, Online Support |
| Usage: | Palletiseren Robot | Power Requirements: | 200-600 V |
| Core Components: | PLC | Max. Payload:: | 700kg |
| Positional Repeatability (mm): | ±0.06 | Max. Reach (mm): | 2540mm |
| High Light: | 6 Axis industrial robot assembly,ZH100U industrial robot assembly,Industrial china robot arm |
||
Product Description
Robotic arm industrial ZH100U 6 axis assembly robot and welding robot with E04 controller
Description:
The ZH100U robot features a short reach and can be installed close to the workpiece. It is well suited for welding applications using a small weld gun.
Application:
- Assembly
- Friction Spot Joining
- Machine Tending
- Material Handling
- Material Removal
- Sealing / Dispensing
- Spot Welding
| ZH100U SPECIFICATIONS | |||
| Product name | Robotic arm industrial ZH100U 6 axis assembly robot and welding robot with E04 controller | ||
|---|---|---|---|
| Type | Articulated Robot | ||
| Degrees of Freedom (axes) | 6 | ||
| Payload (kg) | 100 | ||
| Max. Reach (mm) | 1,634 | ||
| Positional Repeatability (mm) | ±0.3 | ||
| Motion Range (°) | Arm Rotation (JT1) | ±160 | |
| Arm Out-in (JT2) | +120 - −60 | ||
| Arm Up-down (JT3) | +75 - −90 | ||
| Wrist Swivel (JT4) | ±360 | ||
| Wrist Bend (JT5) | ±130 | ||
| Wrist Twist (JT6) | ±360 | ||
| Max. Speed (°/s) | Arm Rotation (JT1) | 140 | |
| Arm Out-in (JT2) | 100 | ||
| Arm Up-down (JT3) | 100 | ||
| Wrist Swivel (JT4) | 150 | ||
| Wrist Bend (JT5) | 150 | ||
| Wrist Twist (JT6) | 250 | ||
| Allowable Moment (N•m) | Wrist Swivel (JT4) | 874 | |
| Wrist Bend (JT5) | 874 | ||
| Wrist Twist (JT6) | 392 | ||
| Allowable Moment of Inertia (kg•m2) | Wrist Swivel (JT4) | 90.0 | |
| Wrist Bend (JT5) | 90.0 | ||
| Wrist Twist (JT6) | 20.0 | ||
| Mass (kg) | 750 | ||
| Mounting | Floor | ||
| Installation Environment | Ambient Temperature (°C) | 0 - 45 | |
| Relative Humidity (%) | 35 - 85 (No dew, nor frost allowed) | ||
| Controller / Power Requirements (kVA) | America & Europe | E02 / 7.5 | |
| Japan & Asia | E02 / 7.5 | ||
Our service:
1.Swift delivery
For common parts, we can deliver the goods within 3 days
2.Original products
All the products we sell are from origin manufacturer. We will submit all the manufacturer documentation while we finish delivery.
3.Quality Assurance
4.Technical Support
Including inspection,repair and maintenance, we can give all kinds of technical support.
5.Quickly responce
Our staffs will keep 24h online and answer your question very quickly.
For common parts, we can deliver the goods within 3 days
2.Original products
All the products we sell are from origin manufacturer. We will submit all the manufacturer documentation while we finish delivery.
3.Quality Assurance
4.Technical Support
Including inspection,repair and maintenance, we can give all kinds of technical support.
5.Quickly responce
Our staffs will keep 24h online and answer your question very quickly.
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company.
Application:
dispensing, finishing, material handling, pick and place, assembly, palletizing, 3d printing, and remote tcp.
Company infomation:
Xiangjing(Shanghai) Mechnical Electrical Tech. Co., Ltd is is the subcompany of Dr. Industry Group Co., Ltd, was founded in January 2015, We focus on discrete industrial automation and process industrial automation, and we can design, develop, install, testing, debug industrial robot, its units and related accessories including fixture, transmission device, positioning device and control system, we can provide Welding Robot, Spray Painting Robot, Transfer Robot, and Grinding Robot, we have many reference in automation industry in China. Meanwhile we are agent of KUKA , ABB, Yaskawa industrial robots, and distributor of FUNC industrial robot. we are the important partner of them in the China market, we have more than 7 engineers with rich expericence, who had been worked for ABB or KUKA more than 10 years. meanwhile Dr. Industry Group can provide ABB and KUKA robot training for our customer, there are weeekly training courses. In the process of industrial automation field, Xiangjing can provide control valve, actuator, postioner, and regulator, Xiangjing is the improtant partner of Emerson process management in the China market, we are fisher and rosemount project authorized agent in China, we can provide fisher control valve, fisher regulator, rosemount pressure, level, thermal transimtter, rosemount wireless instrument, Daniel Flowmeter, ASCO Solenoid Valve, TopWorx Switch and so on. We have many references on power, chemical industry in China. Xiangjing has two teams, one is for discrete industrial automation and the other is for process industrial automation with rich experience, we are good partner of you.
FAQ:
Q.How Long will You Need before Delivery?
A:We have many common models in stock, so that wecan deliver the goods very soon(less than 3 days).
Q.What is Your Payment Term?
A:Normally T/T 30% in advance, balance to be paidbefore delivery, We also support the trade assurance,OlA.
Q:What is Trade Assurance?
A:Trade Assurance is a free service by Alibaba.comthat's designed to help create trust between buyers andsuppliers.Trade Assurance helps buyers in the event ofshipping and quality-related dispute.
Q:Does Trade Assurance Charge Fees?
A:No.Trade Assurance is free for both buyers andsuppliers.
Q:What Kind of Trade Terms Can You Do?
A:EX-WORKS,FOB,CFR,CIF,etc.
