FD-V8 MD350 6 Axis OTC Welding Robot For Tig Mig Industrial Welding
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | OTC |
| Certification: | CE |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wodden cartons or meet customers' requirements |
| Delivery Time: | 6-8 weeks |
| Payment Terms: | L/C, D/A, D/P, T/T |
| Supply Ability: | 999 sets/month |
|
Detail Information |
|||
| Number Of Axes: | 6axis | Pose Repeatability: | ±0.05mm |
|---|---|---|---|
| Warranty Of Core Components: | 1 Year | Type: | OTC Welding Robot Arm |
| After Warranty Service: | Video Technical Support, Online Support | Usage: | Automatic Welding Robot Arm |
| Weight: | 140 Kg | Power Requirements: | 380V |
| Core Components: | PLC, Motor | Drive Capacity: | 3016W |
| High Light: | 380V 6 Axis OTC Welding Robot,380V FD-V8 OTC Welding Robot,380V otc mig welder |
||
Product Description
Robot arm 6 axis OTC FD-V8 laser seam tracking with arc welders MD350 for Tig/Mig Industrial welding robot
FD-V8L 6-axis, long-reach robot is ideal for welding, air-plasma cutting or material-handling. This extended reach arm is ideal reaching large parts.
- Item
- Specifications
- Model name
- NV8L
- Structure
- Vertical articulated type
- Number of Axes
- 6
- Wrist payload
- 8kg
- Weight
- 237kg
- Load of Upper Arm
- 20 kg (*)
ROBOT MANIPULATOR
• Offers a wide working range with an independently articulated arm
• Seamless digital connection with all OTC DAIHEN brand welding power supplies
• Improved vibration restraining control provides smooth robot movement
• Built-in mechanical shock sensor for welding applications
• Single source technology – all components are manufactured by OTC DAIHEN.
• Highly versatile design supports most welding applications
FD11 ROBOT CONTROLLER
• Windows XP based open architecture
• Large memory capacity and 40 Input / 40 Output control signals
• Advanced PLC functions allow for ladder diagram editing directly through the teach pendant
• Network capabilities – connects to Ethernet, DeviceNet, and PROFIBUS connections (may require additional hardware)
TEACH PENDANT
• Icon displays assist in quick & easy teaching
• 640×480 VGA color screen with LED backlight 65536 color display
• 3 position enable switch provides increased safety
• Multi-screen function allows user to view up to 4 screens simultaneously
• On-screen help function with complete instruction manuals
• Standard touch screen display with jog dial operation
Description:
For common parts, we can deliver the goods within 3 days
2.Original products
All the products we sell are from origin manufacturer. We will submit all the manufacturer documentation while we finish delivery.
3.Quality Assurance
4.Technical Support
Including inspection,repair and maintenance, we can give all kinds of technical support.
5.Quickly responce
Our staffs will keep 24h online and answer your question very quickly.
Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company.
Application:
dispensing, finishing, material handling, pick and place, assembly, palletizing, 3d printing, and remote tcp.
